Frequency Response: 60 Hz – 25 kHz
Nominal Impedance: 6 ohms
Sensitivity (1W@1M): 88.5 dB
Maximum SPL: 107.4 dBA
Power Handling (RMS): Z65 W
Recommended Amp Requirements: 20 – 65 W
Drivers Unit Complement: 6 1/2" MMP II cone bass driver 1” C-CAM pivoting Gold Dome tweeter
Adjustment Controls: HF Level Switch (+3 dB / 0 dB / -3 dB)
Overall Diameter: (including grille) 370 mm x 250 mm (14 9/16" x 9 13/16")
Overall Depth: (including grille) 89.5 mm (3 1/2")
Mounting Depth: 85.5 mm (3 3/8")
Cut-Out Hole Diameter: 332 mm x 213 mm (13 1/16" x 8 3/8")
Fixing Type: 6 position Tri-Grip dog fixings
Construction Material: Mineral filled ABS, RoHS compliant
Weight: 2.21 kg (4 lb 14 oz)
Pre-Construction Bracket: WB6 (Purple)
