Monitor Audio IA60-12 Twelve Channel Stereo Amplifier

Elevate your multi-room audio installations with the Monitor Audio IA60-12, a powerful and highly versatile 12-channel amplifier designed to deliver premium sound across multiple zones. Whether you're an integrator fitting out a luxury home, a high-end commercial environment, or a custom AV project, the IA60-12 provides the flexibility, control, and performance needed to meet professional standards.

With 12 channels of Class D amplification, the IA60-12 can power six stereo zones at 60W per channel (into 8 ohms), making it ideal for expansive audio systems. Its 1U rack height, robust build, and DSP control via web interface ensure it integrates seamlessly into modern AV racks while offering effortless configuration. Designed for reliability and scalability, this amplifier is a core component for any premium distributed audio setup.

FEATURES

• 12-Channel Class D Amplification: Drive up to six stereo zones with 60W per channel (at 8 ohms), ensuring crisp, room-filling audio throughout a property.
• 1U Rack-Mountable Design: Space-saving form factor fits effortlessly into standard AV racks, perfect for professional installations where space is at a premium.
• Bridgeable Channels: Bridge adjacent channels to deliver up to 125W (into 8 ohms), allowing more powerful output for high-demand speakers or zones.
• Custom DSP Configuration: Fine-tune audio for every zone with onboard DSP controls accessible via a user-friendly web interface, giving installers maximum flexibility.
• Global and Local Inputs: Offers both local and bus inputs, allowing for flexible signal routing across zones or group playback from a central source.
• Loop Outputs: Feed audio signals to additional amplifiers using the loop output feature, making the IA60-12 perfect for scalable multi-zone installations.
• Ethernet Control & Monitoring: Enables remote configuration and system status monitoring via LAN, streamlining installation and maintenance.
• Energy-Efficient Operation: Advanced Class D technology ensures high efficiency and low power consumption, reducing heat and energy costs.
• Premium Build Quality: Designed by Monitor Audio’s expert engineers, the IA60-12 ensures long-term reliability in demanding environments.

• 'Connect' IP Control: N/A
• Channel Number: 12 (6 Stereo Pairs)
• Power (W / Channel) | 4 ohms: 60 W
• Power (W / Channel) | 8 ohms: 45 W
• Power (W / Channel) | Bridge (8 ohms): 100 W (6CH)
• Power (W / Channel) | 70V: N/A
• Input Impedance: 20 K ohms
• Output Impedance (Loop RCA): 600 ohms
• Input Sensitivity: 100 mV / 1 W, 700 mV – Full power
• Maximum Input Voltage: 2.9 V
• Signal to Noise (SN:R): -100 dB (20 Hz – 20 kHz)
• Frequency Response: 5 Hz – 50 kHz
• Total Harmonic Distortion THD + N@1 KHz: 0.03%
• Rack Height: 2U
• Dimensions (Excluding Feet (H x W x D)): 86.8 x 438 x 427 mm (3⁷/₁₆ x 17¹/₄ x 16¹³/₁₆)
• Dimensions (Including Feet (H x W x D)): 97.2 x 438 x 427 mm (3¹³/₁₆ x 17¹/₄ x 16¹³/₁₆)
• Width (including rack brackets): 482 mm (19")
• IP Communication: N/A
• Mains Operating Voltage: 100 –120 V @ 60 Hz, 220 – 240 V @ 50 Hz
• Fuse Rating: 10 A (T10AL ~ 250VAC)
• Standby Power Consumption: <0.5 W (green mode)
• Networked Standby Power Consumption: N/A
• Weight: 7.34 kg (16 lb 2 oz)
• Sold As: Single Unit
• Warranty: 5 years

• 1 x Amplifier
• 1 x Mains Lead
• 1 x Connectors Set
• 2 x Rack Mount Ears
