Elipson A680 480W 3 Zone Stereo Power Amplifier
Includes 2 Years Warranty + 60 Day Returns
Need Advice? Call 02393 190955
Need Advice? Call 02393 190955
We’re more than just an online retailer. We’re passionate about audio and offering the best customer service in the industry.
Need some advice? Call our audio experts on 02393 190955, live chat or email us and we’ll help you make the best decision. Learn More
Spend £99 For Free Delivery
Spend £99 For Free Delivery
All orders to mainland UK over £99 are eligible for free standard delivery.
Need it fast? No problem, you’ll find express next day delivery rates available on most products. Learn More
Extended 60 Day Returns
Extended 60 Day Returns
We’re so confident that you’ll be happy with your purchase that we’ve extended our returns policy to 60 days. We call it the “Happy Sound Guarantee”.
If you’re not happy with your purchase for any reason simply send it back to us for a full refund. Learn More
Description
Description
The Elipson A680 is a three zone multi channel amplifier to produce high quality sound in up to three zones.
Link multiple amplifiers together for larger systems.
Add a WiFi streamer input to each zone or select from two bus inputs to sync multiple channels together.
Perfect for multi room audio installations and larger projects requiring multiple speakers.
FEATURES
- 6 x Channel – 3 x stereo class D (Total power of 480 W @ 4 Ohms)
- 3 x Zones
- 2 x Bus inputs
- 2 x Bus outputs to connect more A680 multichannel amplifiers
- Perfect flexibility for audio signal input : Switch for common audio signal (Bus) or individual stereo channel (line) for each zone - 6 Individual adjustment for voltage input
- Trigger mode / auto mode / automatic Standby mode
- Stereo / Bridge mode (up to 3 x 150 W @ 8 Ohms)
Key Features
Key Features
-
ZonesSingle Zone
-
PlacementFreestanding
-
InputsRCA
-
OutputsRCA Line Out
-
Warranty
Specifications
Specifications
- Type: Multi-channel power amplifier
- Channels: 6 channels, 3 zones
- Output Power: 80 watts / channel @ 4 Ohms
- Bridge mode output power: 150 watts / channel @ 8 Ohms
- Total harmonic distortion: <1% 1 kHz / 80 W / 4 Ohms
- Channel Separation: > 65 dB / 1 kHz 4 Ohms Zone-Zone
- Signal-to-noise ratio: > 90 dB (19V - A-weighting)
- Frequency response: 20 Hz - 20 kHz (+/- 3 dB)
- Trigger: 12V IN & OUT
- Damping factor: > 55 (1 kHz)
- Input impedance: > 20 k Ohms
- Input voltage: AC 100 - 120 V 60 Hz / AC 220 - 240 V 50 Hz
- Auto Switching
- Certifications: CE, CB, NRT, FCC, CE-EMC, ERP
- Dimensions: W430 x H88* x D335 mm
- Weight: 9.5 kg
