Monitor Audio W2M-CP Creator Series In Wall Speaker - Medium (Each)

This medium-sized Tier 2 in-wall loudspeaker is a three-way model featuring two RST II bass drivers, an RST II mid-range driver, and a C-CAM tweeter.

Its fully sealed back box delivers consistency of performance, no matter where it is used.

It has a cut-out dimension of 527 x 198 mm and a revolutionary Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable, and strong installation and fitting.

• Ideal for installations where pristine acoustic performance is required
• Filled back box
• Three-way design
• 1 x 1" C-CAM tweeter with UD Waveguide II for lifelike sound
• 1 x 3" RST II mid-range driver
• 2 x 5" RST II bass drivers
• Quik-Link speaker cable connector for quicker installation
• Tri-Grip II for easy and secure fitment

What You Get

• 1 x In Wall Speaker
• 1 x Grille
• 1 x Cut Out Template
• 1 x Manual

Specifications

• System Format: 3–Way
• Channels: 1
• Frequency Response, Installed (-6dB): 60 Hz – 35 kHz
• Nominal Impedance: 6 ohm
• Minimum Impedance (20Hz to 20kHz): 4.8 Ohm @ 1 kHz (4.3 Ohm @ 15 kHz)
• Sensitivity (2.83Vrms@1m, Installed): 87 dB
• Maximum Peak SPL (single speaker @ 1m Z-Weighted): 118 dB
• Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor): 100 W
• Recommended Amplifier Power (RMS into 8 OHM, Music Signal): 40 – 150 W
• Drive Unit Complement: 2 x 5"(127 mm) RST II bass driver, 1 x 3"(76 mm) RST II mid-range driver, 1 x 1"(25 mm) C-CAM tweeter
• Crossover Frequency: LF/HF: 550 Hz, MF/HF: 3 kHz
• Bass Alignment: Sealed
• Mounting Depth: 97 mm (3 13/16")
• Cutout (L x W): 527 x 198 mm (20 3/4 x 7 13/16")
• External Dimensions (Including Grille, H x W x D): 560 x 231 x 102 mm (22 1/16 x 9 1/8 x 4 1/64")
• Weight (each): 4.4 kg
• Pre-Construction Bracket: WM-B
• Cabinet Finish: Matte black&Orange&Bronze
• Sold As: Single Unit
• Corner Switch: On/Off
• HF Switch: - / 0 / +
• Warranty: Lifetime
