Monitor Audio C3M Creator Series In Ceiling Speaker - Medium (Each)

This high-performance, medium-sized Tier 3 in-ceiling loudspeaker is a three-way model featuring an RDT III bass driver, IDC II midrange driver and IDC II tweeter with UD Waveguide II.

It has a cut-out dimension of 212 mm and a revolutionary Quik-Link speaker cable connector and Tri-Grip II for quick, simple, reliable, and strong installation and fitting.

• Ideal for installations where high-performance acoustics are desired
• Three-way design
• Mid-frequency ‘mid-pod array’
• 1 x 1" IDC II tweeter with UD Waveguide II for lifelike sound
• 1 x 7" RDT III bass driver
• 1 x 4" IDC II midrange driver
• Quik-Link speaker cable connector for quicker installation
• Tri-Grip II for easy and secure fitment

What You Get

• 1 x In Ceiling Speaker
• 1 x Grille
• 1 x Cut Out Template
• 1 x Manual

Specifications

• System Format: 3–Way
• Channels: 1
• Frequency Response, Installed (-6dB): 45 Hz – 35 kHz
• Nominal Impedance: 6 ohm
• Minimum Impedance (20Hz to 20kHz): 4.8 Ohm @ 2 kHz
• Sensitivity (2.83Vrms@1m, Installed): 87 dB
• Maximum Peak SPL (single speaker @ 1m Z-Weighted): 116 dB
• Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor): 120 W
• Recommended Amplifier Power (RMS into 8 OHM, Music Signal): 45 – 180 W
• Drive Unit Complement: 1 x 7"(178 mm) RDT III bass driver, 1 x 4"(102 mm) IDC II midrange driver, 1 x 1"(25 mm) IDC II tweeter
• Crossover Frequency: LF/MF: 800 Hz, MF/HF: 3.5 kHz
• Mounting Depth: 148 mm (5 13/16")
• Cut-Out Hole Diameter: 212 mm (8 3/8")
• External Dimensions (Including Grille, H x W x D): 242 x 242 x 151 mm (9 1/2 x 9 1/2 x 5 15/16")
• Weight (each): 3.4 kg
• Pre-Construction Bracket: CM-B
• Cabinet Finish: Matte black&Orange&Green
• Sold As: Single Unit with CM-Round Grille (white)
• Corner Switch: On/Off
• HF Switch: - / 0 / +
• MF Switch: - / 0 / +
• Warranty: Lifetime
