Monitor Audio C1S Creator Series In Ceiling Speaker - Small (Each)

This small Tier 1 in-ceiling loudspeaker is a two-way model featuring a C-CAM mid-bass driver and C-CAM tweeter.

It has a cut-out dimension of 171 mm, a revolutionary Quik-Link speaker cable connector, and Tri-Grip II for quick, simple, reliable, and strong installation and fitment.

• Ideal for cost-effective installations
• Two-way design
• 1 x 1" C-CAM tweeter with UD Waveguide
• 1 x 5" C-CAM mid-bass driver
• Quik-Link speaker cable connector for quicker installation
• Tri-Grip II for easy and secure fitment

What You Get

• 1 x In Ceiling Speaker
• 1 x Grille
• 1 x Cut Out Template
• 1 x Manual

Specifications

• System Format: 2–Way
• Channels: 1
• Frequency Response, Installed (-6dB): 40 Hz – 30 kHz
• Nominal Impedance: 8 ohm
• Minimum Impedance (20Hz to 20kHz): 6.6 Ohm @ 150 Hz
• Sensitivity (2.83Vrms@1m, Installed): 84 dB
• Maximum Peak SPL (single speaker @ 1m Z-Weighted): 110 dB
• Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor): 50 W
• Recommended Amplifier Power (RMS into 8 OHM, Music Signal): 25 – 100 W
• Drive Unit Complement: 1 x 5"(127 mm) C-CAM mid-bass driver, 1 x 1"(25 mm) C-CAM tweeter
• Crossover Frequency: LF/HF: 3 kHz
• Mounting Depth: 99 mm (3 7/8")
• Cut-Out Hole Diameter: 171 mm (6 3/4")
• External Dimensions (Including Grille, H x W x D): 201 x 201 x 103 mm (7 15/16 x 7 15/16 x 4 4/16")
• Weight (each): 1.4 kg
• Pre-Construction Bracket: CS-B
• Cabinet Finish: Matte black&Orange
• Sold As: Single Unit with CS-Round Grille (white)
• Warranty: Lifetime
